Interfaces

  Total Port

  52 Ports

  Max POE Output

  1200Watt

  POE Port Control

 Texas Instruments Chipset

  Fast RJ45 POE Port

  N/A

  Gigabit RJ45 POE Port

  48 Port

  Fast RJ45 Uplink Port

  N/A

  Gigabit RJ45 Uplink Port

  N/A

  Gigabit SFP Uplink Port

  4

  Combo Uplink Port

  N/A

  Network Performance

  Standard

  IEEE802.3x, IEEE802.3u, IEEE802.3az, IEEE802.3ab, IEEE802.3af, IEEE802.3at(Up to 30Watt), IEEE802.3bt

  Protocols

  CSMA/CD

  Router

  N/A

  Speed

  Ethernet 10Mbps (half duplex), 20Mbps (full duplex); 10BASE-T: 14,880bps/port

  Fast Ethernet 100Mbps (half duplex), 200Mbps (full duplex); 100BASE-TX:14,8800bps/port

  Gigabit Ethernet 1000Mbps (half duplex), 2000Mbps (full Duplex); 1000BASE-TX: 1488000bps/port

  Cabling

  10Base-TX: Cat 5 or above (120m) POE=120M
100Base-TX:Cat 6 UTP(100m) POE=120M
1000Base-TX: Cat 6 UTP or above (100m) POE=120M

  Bandwidth

  104Gb Internal Bandwidth

  MAC Table

  512Kb

  Auto MDI-MDIX

  Yes All Port

  Console

  Yes – Web & RS232(Talent Support) Layer2 Management

  Transfer Pattern

  Store & Forward

  Hardware

  Processore Type

  Realtek

  LED Panel

  POE Activity / Data Activity

  Main Board

  Four Layer

  Case

  Metal Case

  Mounting

  Rackmount

  PD`S

  IP Camera

  Yes

  IP Phone

  Yes

  (+)5/4,(-)8/7

  Optional

  (+)2/1,(-)6/3

  Yes

  General

  IP Rating

  IP51

  Web Language

  English

  Dimension

  440*338*45 mm

  Weight

  4.5 Kg

  Storage Temp

  -20°~+60°C / 10%~90%RH

  Operation Temp

  -15°~+50°C / 10%~90%RH

  Radiation Electromagnetic

  EN55016

  Status

  LED

  Ethernet Interfaces
1000 LNK/ACT (Green), 10/100 LNK/ACT (Green)
PoE Ethernet Interfaces, PoE-in-Use (af/at/bt)
1000 LNK/ACT (Orange), 10/100 LNK/ACT (Green)

  Power Supply

  Power

  200~240V AC, 50~60Hz

  Redundant

  N/A

  LED Power

  Yes

  Power Cable

  Available

  Guarantee

  Product Guarantee

  3 Year Platinum Guarantee

  MTBF

  100K hrs min. MIL-HDBK-217F (25°)
