CPU & Capabilities

CPU

Dual-Core ARM Cortex-A17 @1600 MHz

IP Channel Input

64CH x 4K @30fps (Up to 12MP Supported)

Video & Audio

HDMI Output

2CH / 1CH 4K (3840 x 2160) , 1CH Full HD (1920 x 1080)

VGA Output

1CH x Full HD (1920 x 1080)

Audio Input/Output

1CH Input, 1CH Output

Recording

Video Compression

H.264+(Ultra H.264), H.265+ (Ultra H.265) Smart Event Codec

Audio Compression

G.711A, G.711U

Video Resolution

12MP, 8MP, 5MP, 4MP, 3MP, 1080P, 720P, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF

Input Bandwidth

320~500Mbps (Smart Bandwidth Management System) when RAID is enabled

Record Mode

Manual, Schedule, Alarm, Event, Smart Event

Failover

N+1 Hot Spare

Pre & Post Record

Pre 1~30 sec, Post 10~300 sec

Playback & Backup

Sync Playback

16CH Sync Playback (Up to 4K@30fps)

Search Mode

Time & Date, Motion, Alarm Input, All Smart Function

Playback Mode

Normal, Time Division, Label, Event, Picture Playback, Smart Playback, ANR Support

Backup Mode

USB Device, Network, Internal SATA Burner

Network & Monitoring

Protocols

HTTPS, HTTP, TCP/IP V4-V6, ICMP, RTSP, UDP, NTP, DHCP, DDNS, FTP, SNMP-V1-V2-V3, UPnP, P2P, NAT, Multi Cast

Compatibility

Onvif Ver2.6, Profile S, G, T, CGI, SDK, API

Output Bandwidth

100~300Mbps (Smart Bandwidth Management System) when RAID is enabled

User

32 Users

Streaming Method

Unicast, Multicast

Web Viewer

IE, Edge, Firefox, Chrome

Windows Software

Unlimited KDT CMS/VMS

Smart Device

IOS, Android Phone & Tablet

Hard Disk

HDD

8 SATA HDD

Capacity

Up To 14 TB For Each HDD

Raid Support

Raid 0-1-3-5-10

Group HDD

Yes

External Interface

Network

2 x RJ45(10/100/1000Mbps)+LED Indicator, 2 x Gigabit SFP Port

Wifi / 4G Dongle

Supported

USB Interface

Front Panel: 2 x USB 2.0 / Rear Panel: 1 x USB 3.0

eSATA

1

Alarm In / Alarm Out

16 / 4

Controller

2 x RS-485 Interface

Smart Function

Smart Function

20 Smart Function

Intelligent Function

Line Crossing,Area Intrusion,Face Detection,Audio Exception Detection,Unattended Objects,Object Missing,Region Entrance,Region Exiting,Fast Moving,Loitering Detection,People Gathering Detection,Parking Detection,Blurred Detection,Scene Change Detection,People Counting,Video Shelter,Motion Detection,Human Detection,Car Shape Detection

General

Power Supply

200~240V AC, 50~60Hz

Power Consumption

<30 W Without Hard Disk

Working Environment

-20°C ~ +50°C / 10% ~ 90% RH (Non condensing)

Rackmount

Yes 2 Unit

Dimension

440*452*90 mm

Weight

7.3 Kg Without HDD

Sustainable Transfer Rate

Raid 3, 5

Up to 180 mb/s in HDD Seagate Sky HDD (Depend on Model)

Raid 3, 5

Up to 245 mb/s in HDD Western Digital Purple (Depend on Model)

Raid 0, 1, 10

Up to 180 mb/s in HDD Seagate Sky HDD (Depend on Model)

Raid 0, 1, 10

Up to 145 mb/s in HDD Western Digital Digital Purple (Depend on Model)

Playback

4 Channels Simultaneous for All Raid

Guarantee

Product Guarantee

3 Years Platinum Guarantee

MTBF

100k hrs min. MIL-HDBK-217F (25°)
