CPU & GPU Capabilities

CPU

Quad-Core ARM Cortex-A76@ & Quad-Core ARM Cortex-A55

GPU

ARM Mali-G610MC4

IP Channel Input

128CH x 8K@30fps (Up to 32MP Supported)

Video & Audio

Video Output Mode

4CH HDMI video output 2CH VGA
Simultaneous mode

• max. resolution of HDMI1 is 8K
• max. resolution of HDMI2, HDMI4 is 4K
• max. resolution of VGA1, VGA2, HDMI3 is 1080P

Heterologous mode

• Simultaneous video source output for VGA1 and HDMI4
• Simultaneous video source output for VGA2 and HDMI2
• max. resolution of HDMI1, HDMI4 and HDMI2 is 4K
• max. resolution of HDMI3 is 1080P
• max. resolution of VGA1 and VGA2 is 1080P

Output 1 HDMI

7680 x 4320/30Hz, 3840 x 2160/30Hz, 1920 x 1080/60Hz

Output 2 HDMI

3840 x 2160/60Hz, 1920 x 1080/60Hz, 1280 x 1024/60Hz

Output 3 HDMI

1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz

Output 4 HDMI

3840 x 2160/30Hz, 1920 x 1080/60Hz, 1280 x 1024/60Hz

Output 1 VGA

1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz

Output 2 VGA

1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz

Main/Secondary Screen Split

1,4,8.9,16,25.36.64 screen split

Audio Output

2CH, RCA

Recording

Video Compression

H.264+(Ultra H.264), H.265+ (Ultra H.265) Smart Event Codec

Audio Compression

G.711A, G.711U

Video Resolution

32MP, 16MP, 12MP, 8MP, 5MP, 4MP, 3MP, 1080P, 720P, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF

Input Bandwidth

1024Mbps or 512 Mbps (when RAID is enabled)

Record Mode

Manual, Schedule, Alarm, Event, Smart Event

Failover

N+1 Hot Spare

Pre & Post Record

Pre 1~30 sec, Post 10~300 sec

Playback & Backup

Decoding Capability

H.265
32CH 1080P@30fps
16CH 4Mp@30fps
8CH 8Mp@30fps
4CH 16Mp@30fps
2CH 32Mp@30fps

H.264
16CH 1080P@30fps
8CH 4Mp@30fps
4CH 8Mp@30fps
2CH 16Mp@30fps
1CH 32Mp@30fps

Sync Playback

16CH Sync Playback (Up to 4K@30fps)

Search Mode

Time & Date, Motion, Alarm Input, All Smart Function

Playback Mode

Normal, Time Division, Label, Event, Picture Playback, Smart Playback, ANR Support

Backup Mode

USB Device, Network, Internal Sata Burner, Cloud Storage

Network & Monitoring

Protocols

HTTPs, HTTP, TCP/IP V4-V6, ICMP, RTSP, UDP, NTP, DHCP, DDNS, FTP, SNMP-V1-V2-V3, UPNP, P2P, NAT, Multi Cast

Compatibility

Onvif Ver2.6, Profile S, G, T, CGI, SDK, API

Output Bandwidth

800Mbps or 400 Mbps (when RAID is enabled)

User

32 Users

Streaming Method

Unicast, Multicast

Web Viewer

Internet Explorer

Windows Software

Unlimited KDT CMS/VMS

Smart Device

IOS, Android Phone & Tablet

Hard Disk

HDD

16 Sata HDD with Cage (Hot Swap Technology)

Capacity

Up To 22 TB For Each HDD

Raid Support

Raid 0-1-5-6-10-50-60

Group HDD

Yes

External Interface

Network

3x RJ45/ 1x 2.5GE Or 3x self-adaptive Ethernet interface, (10/100/1000Mbps)+LED Indicator
2 x Gigabit SFP Port

WiFi / 4G Dongle

Supported

USB Interface

Front Panel: 2 x USB 2.0 / Rear Panel: 1 x USB 3.0, 1 x USB 2.0

eSATA

2

Alarm In / Alarm Out

16 / 8

Controller

1 x RS-485 Interface / 1 x RS-232

12V Out

1

Smart Function

Intelligent Function

20 Smart Functions:
Line Crossing, Area Intrusion, Face Detection, Audio Exception Detection,
Unattended Objects, Object Missing, Region Entrance, Region Exiting, Fast Moving,
Loitering Detection, People Gathering Detection, Parking Detection, Blurred Detection,
Scene Change Detection, People Counting, Video Shelter, Motion Detection,
Human Detection, Car Shape Detection

General

Power Supply

200~240V AC, 50~60Hz

Power Consumption

≤90 W Without Hard Disk

Power Redundant

N/A

Working Environment

-20°C ~ +50°C / 10% ~ 90% RH (Non condensing)

Rackmount

Yes, 4 Units

Dimension (WxDxH)

485*435*145 mm

Weight

11 Kg Without HDD

Guarantee

Product Guarantee

3 Years Platinum Guarantee

MTBF

100K hrs min. MIL-HDBK-217F (25°)
