KI-T37LM05F-S
30~40 m White Light Technology
12 mm Fixed Lens @F1.2 Full Color
PRODUCTS
Innovative Technology | Reliable Quality | End-to-End Service
دوربین مداربسته کی دی تی مدل KI-T37LM05F-S
سایر برتری ها:
- پشتیبانی از میکرو SD با ظرفیت 256GB
- بدنــه ضد آب و گـرد و غبـــار با درجه IP67
- پشتیبـــــانی از +H.264+ / H.265
- پشتیبانی از ONVIF ورژن 2.6
- قـــــابلیت دیـــد در شــب هـوشمنــــد
- قابلیت WDR, BLC, HLC, Defog و ROl تا 8 ناحیه
KI-T37LM05F-S
- Detector Type: Uncooled VOx
- Vehicle (2.3*2.3m): Detection 3300m Recognation 830m, Identification: 420m
- Human (1.85*0.5m): Detection 1400m, recognation 350m, Identification: 180m
- IP Rating: IP66
- Support Electronic Image Stabilization
- Onvif, Ver2.6
- 1 RJ45 (10M / 100M) Ethernet Port
- Micro SD/SDHC/SDXC Slot (256 Gb Max)
شرایط گارانتی :
- دو سال گارانتی طلایی بدون قید و شرط کی دی تی
- سه سال ضمانت پایداری کیفیت تصویر
- شامل: آبخوردگی، شکستگی، ضربه دیدگی، خسارت ناشی از صاعقه، زنگ زدگی، نوسانات برق، سایر اتفاقات و صدمات
| Camera | |
| Image Sensor | Uncooled VOx |
| Detector Type | N/A |
| Array Pixel | 640×512 |
| Pixel Pitch | 17µm |
| Lens | 37mm Fixed @F1.1 |
| Lens Mount | N/A |
| Resolution | N/A |
| Angle of View | 16-8°-12.8° |
| Available IR Range | N/A |
| D/N Filter | N/A |
| Min illumination | N/A |
| Night Vision | N/A |
| Web Viewer | Internet Explorer |
| Smart Device | N/A |
| Recording | |
| Recording | FTP, NVR, CMS |
| Record Type | Manual, Motion Detection, Smart Detection, Schedule |
| Alarm Triggers | Motion Detection |
| Event Action | N/A |
| Event | N/A |
| Intelligent Function | N/A |
| Picture Adjust | |
| Effective Distance |
Vehicle (2.3×2.3m): Detection 3300m, Recognition 830m, Identification 420m Human (1.85×0.5m): Detection 1400m, Recognition 350m, Identification 180m |
| Shutter Speed | N/A |
| Image Parameter Control | Off, On, Timing (Adjust 0~255) |
| D/N Control | N/A |
| Image Parameter | N/A |
| Image Stabilization | Support Electronic Image Stabilization |
| Digital Zoom | 16X |
| Optical Defog | N/A |
| Electrical Zoom | 4X |
| Network | |
| Network | 1 RJ45 (10M / 100M) Ethernet Port |
| Audio | N/A |
| Alarm | N/A |
| CVBS | N/A |
| Power | PoE LAN / Power IN |
| Control | 1×RS422 |
| Reset Button | N/A |
| Memory Slot | Yes – Micro SD/SDHC/SDXC Slot (256GB Max) |
| Video / Audio | |
| Video Compression | H.265, H.264, MJPEG |
| Audio Compression | G.711A, G.722.1, G.7726, MP2L2 |
| Frame Rate (50Hz) | 25fps@640×480 |
| Transmission Stream | N/A |
| Network | |
| Protocols | HTTP, TCP/IP v4, RTSP, NTP |
| Compatibility | ONVIF Ver2-6 |
| Streaming Method | N/A |
| Web Viewer | Internet Explorer |
| Smart Device | N/A |
| Interface | |
| Network | 1 RJ45 (10M / 100M) Ethernet Port |
| Audio | N/A |
| Alarm | 1/1 |
| CVBS | N/A |
| Power | DC In |
| Control | 1×RS422 |
| Reset Button | N/A |
| Memory Slot | Yes – Micro SD/SDHC/SDXC Slot (256GB Max) |
| General | |
| IP Rating | IP66 |
| Wiper | Yes |
| Power Consumption | 60W (Normal Work Under Normal Temperature) |
| Power Supply | AC24V ±15% |
| POE Supply | N/A |
| Web Language | English |
| Dimension | 280×80 mm |
| Weight | 1.4 kg |
| Operation Humidity | Max Up To 95% RH (Non-Condensing) |
| Operation Temp | -40℃ ~ +60℃ |
| Storage Temp | -45℃ ~ +70℃ |
| Guarantee | |
| Product Guarantee | 2 Years Silver Guarantee |
| MTBF | 100K hrs min. MIL-HDBK-217F (25°) |
