Camera

Image Sensor

2MP (Sony-Japan) Progressive scan Cmos Sensor (1/2.8″)

CPU

Dual-Core ARM 2 x A53@1400 MHz

Lens

7~22mm Motorized 3X Optical Zoom (F-Stop F1.6-F2.8)

Resolution

1920*1080 (2MP)

Available IR Range

100*110 m Smart IR SMD (Osram-Germany) Technology

D/N Filter

IR Cut Filter Switch (ICR)

Min illumination

Color: 0.002 Lux(AGC on) – B/W: 0.0 Lux(IR on)

Angle of View

H-FOV: 40°~16°, V-FOV: 23°~9°, D-FOV: 46°~19°

Night Vision

Color / IR

Picture Adjust

Picture Function

140 dB WDR/DWDR, Defog, AWB, EIS, 2D/3D DNR, BLC, HLC, ROI, Anti-flicker, Corridor Mode, Deblur

Shutter Speed

Manual (1/3 ~ 1/100.000), Auto

Image Parameter Control

Off, On, Timing (Adjust 0 ~ 255)

D/N Control

Timing, Auto, Color on, Color off

Image Parameter

Saturation, Brightness, Contrast, Sharpness, Hue

Video / Audio

Video Compression

H.264+(Ultra H.264), H.265+ (Ultra H.265) MJPEG

Audio Compression

G.711A, G.711U

Frame Rate(60Hz)

90fps@1920×1080, 1280×960, 1280×720, 704×576

Transmission Stream

Dual Stream (Code Rate: 256kbps-16mbps)

Network

Protocols

IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, QoS

Compatibility

Onvif Ver2.6, Profile S/G/Q/T, API, SDK, CGI

Streaming Method

Unicast, Multicast

Web Viewer

IE, Edge, Firefox, Chrome

Smart Device

iOS, Android Phone & Tablet

Function

Recording

FTP, NVR, CMS, VMS, NAS, SD Card

Record Type

Manual, Motion Detection, Schedule

Alarm Triggers

N/A

Event Action

Email, PTZ, Snapshot, Recording, Alarm Out, Buzzer, Pop up, Show Message

Event

Smart Motion Detection, Video Shelter

Intelligent Function

N/A

Interface

Network

1 RJ45 (10M / 100M) Ethernet Port

External Audio

Audio Out, Audio In

Internal Audio

Internal Mic, Internal Speaker

Alarm

Alarm In, Alarm Out

CVBS

Yes

Power

PoE LAN, DC In

Reset Button

Yes (Optional)

Memory Slot

Yes – Micro SD/SDHC/SDXC Slot (256 Gb Max)

General

Protection Rating

IP67, IK10, 6KV Surge Protection

Back Box

Yes

Power Supply

DC12V ± 25%

POE Supply

IEEE802.3af – Max 13 Watt

Web Language

English, Persian

Dimension

285*126 mm

Weight

2 Kg

Operation Humidity

Max Up to 95%RH (Non Condensing)

Operation Temp

-40°C ~ +70°C

Guarantee

Product Guarantee

2 Years Silver Guarantee

MTBF

100K hrs min. MIL-HDBK-217F (25°)

Certificates

EN, CN, FCC, CFR
