Camera

  Image Sensor

  6MP (Sony-Japan) Progressive scan Cmos Sensor (1/2.8”)

  CPU

  Dual-Core ARM Cortex-A7@900MHz

  Lens

  5~50 mm @F1.6, Motorized Fast Auto Focus Lens

  Resolution

  3200*1800 (6MP)

  Available IR Range

  100~110 m Smart IR SMD(8PCS)(Osram-Germany) Technology

  D/N Filter

  IR Cut Filter With Auto Switch

  Min Illumination

  Color: 0.001  lux(AGC on) – B/W: 0.0 Lux(IR on)

  Angle of View

  H-FOV: 48.3°~9.1°, V-FOV: 27.1°~5.1°, D-FOV: 54°~10.5°

 Night Vision

Color /IR

 Red/Blue Light Warning

Flash: 5 s–30 s; frequency: high/medium/low

  Picture Adjust

  Picture Function

  120dB WDR/DWDR, 2D/3D DNR, BLC, HLC, ROI, Defog

  EIS /DIS

  Yes (Optional)

  Shutter Speed

  Manual (1/3 ~ 1/100.000), Auto

  Image Parameter Control

  Off, On, Timing (Adjust 0 ~ 255)

  D/N Control

  Timing, Auto , Color on, Color off

  S/N

 > 58dB

  Image Parameter

  Saturation, Brightness, Contrast, Sharpness, Hue

  Video/Audio

  Video Compression

  H.264+(UltraH.264), H.265+(UltraH.265)

  Audio Compression

  G.711A, G.711U

  Frame Rate(60Hz)

  30fps@ 6MP(3200*1800), 30fps@ 4MP, 60fps@ 2MP

  Transmission Stream

  Triple Stream (Video Bit Rate:11 Kbps~16 Mbps)

  Network

  Protocols

  TCP/IP(V4, V6), ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, IGMP, UPnP, SMTP, UPnP-TM, P2P, Bonjour, SNMP (V1, V2, V3), UDP, NAT, Multicast, RTMP

  Compatibility

  Onvif Ver2.6, Profile S, G, T, CGI, SDK, API

  Streaming Method

  Unicast, Multicast

  Web Viewer

  IE, Edge, Firefox, Chrome

  Smart Device

  IOS, Android Phone & Tablet

  Function

  Recording

  FTP, NVR, CMS, VMS, NAS, SD Card, ANR

  Record Type

  Manual, Motion Detection, Smart Detection, Schedule

  Alarm Triggers

  All Intelligent Function

  Event Action

  Email, PTZ, Snapshot, Recording, Buzzer, Pop up, Show Message. Smart Light

  Event

  Motion Detection, Video Shelter

  Intelligent Function

  17 Smart Function
  Line Crossing, Area Intrusion, Region Entrance, Region Exiting, Fast Moving, Loitering Detection, People Gathering Detection, Blurred Detection, Scene Change Detection, Audio exception Detection, Crossing Line Statistics, Face Detection, Human Detection, Car Shape Detection, Smart People Counting, Crowd Density Monitorring, Heat Map

  Interface

  Network

 1 RJ45 (10M / 100M) Ethernet Port

  Audio

  Internal Mic, Audio Out, Audio In

  Alarm

  Alarm Out, Alarm In

  CVBS

  N/A

  Power

  PoE LAN, DC In

  Reset Button

  Yes (Optional)

  Memory Slot

  Yes – Micro SD/SDHC/SDXC Slot (256 Gb Max) (ANR Support)

  General

  IP Rating

  IP67, IK10, 6KV Surge Protection

  Junction Box

  Yes

  Power Supply

  DC12V ± 10%

  POE Supply

  IEEE802.3af – Max 15 Watt

  Web Language

  English, Persian

  Dimension

  360*140 mm

  Weight

  2.9 Kg

  Operation Humidity

  Humidity 95% or less (non-condensing)

  Operation Temp

  -30°C ~ +60°C

 Guarantee

  Product Guarantee

  5 Years Gold Guarantee

  MTBF

  100K hrs min. MIL-HDBK-217F (25°)

  Certificate

  EN, CN, FCC, CFR
