Interfaces

Total Port

36 Ports

POE Output (Max)

N/A

POE Port Control

N/A

Fast RJ45 POE Port

N/A

Gigabit RJ45 Port

8

Fast RJ45 Uplink Port

N/A

Gigabit RJ45 Uplink Port

N/A

Gigabit SFP Uplink Port

24

10 Gigabit SFP Uplink Port

4

Storage Port

Yes (1 USB 2.0)

Combo Uplink Port

Yes (Port 1~8)

Network Performance

Standard

IEEE 802.3i, 802.3u, 802.3ab, 802.3z, 802.3ae, 802.3av, 802.3x, 802.3ad, 802.1v, 802.1d, 802.1s, 802.1w, 802.1q, 802.1p

Protocols

CSMA/CD

Router

Yes

Speed

Ethernet 10Mbps (half duplex), 20Mbps (full duplex); 10BASE-T: 14,880bps/port; Fast Ethernet 100Mbps (half duplex), 200Mbps (full duplex); 100BASE-TX:14,8800bps/port; Gigabit Ethernet 1000Mbps (half duplex), 2000Mbps (full duplex); 1000BASE-TX: 1488000bps/port; 10 Gigabit Ethernet 10000Mbps (half duplex), 20000Mbps (full duplex).

Cabling

10Base-TX: Cat 5 or above (250m) POE=250M; 100Base-TX: Cat 6 UTP(100m); 1000Base-TX: Cat 6 UTP or above(100m)

Bandwidth

128Gb Internal Bandwidth

MAC Table

64Kb

Jumbo Frame

12Kb

Packet Buffer

16Mb

Packet Forwarding Rate

95.23 Mp/s (Mega Packet Per Second)

Auto MDI-MDIX

Yes All Ports

Console

Yes – Web & RS232 Layer3 Management (Telnet / SSH / CLI)

Transfer Pattern

Store & Forward

Hardware

Processor Type

Realtek

LED Panel

POE Activity, Data Activity, Power Activity

Main Board

Double Layer

Case

Metal Case

Mounting

Rackmount

IP Camera

N/A

IP Phone

N/A

(+5)/4,(-)8/7

N/A

(+2)/1,(-)6/3

N/A

General

Protection Rating

IP51

Web Language

English

Dimension

440*273*45 mm

Weight

2.900 kg

Storage Temp

-20°C ~ +60°C / 10% ~ 90% RH

Operation Temp

-15°C ~ +50°C / 10% ~ 90% RH

Radiation Electromagnetic

EN55016

Power Supply

Power

200~240V AC, 50~60Hz

Redundant

N/A

LED Power

Yes

Power Cable

Available

Guarantee

Product Guarantee

3 Years Platinum Guarantee

MTBF

100K hrs min. MIL-HDBK-217F (25°)
