Interfaces

  Total Port

  11 Ports

  Max POE Output

  N/A

  POE Port Control

  N/A

  Fast RJ45 POE Port

  N/A

  Gigabit RJ45 POE Port

  2

  Fast RJ45 Uplink Port

  N/A

  Gigabit RJ45 Uplink Port

  N/A

  Gigabit SFP Uplink Port

  9

  Combo Uplink Port

  N/A

  Network Performance

  Standard

  IEEE802.3x, IEEE802.3u, IEEE802.3az, IEEE802.3ab

  Protocols

  CSMA/CD

  Router

  N/A

  Speed

  Ethernet 10Mbps (half duplex), 20Mbps (full duplex);
10BASE-T: 14,880bps/port
Fast Ethernet 100Mbps (half duplex), 200Mbps (full duplex);
100BASE-TX:14,8800bps/port
Gigabit Ethernet 1000Mbps (half duplex), 2000Mbps (full duplex);

1000BASE-TX: 1488000bps/port

  Cabling

  10Base-TX:Cat 5 or above (100m)
100Base-TX:Cat 6 UTP(100m)
1000Base-TX:Cat 6 UTP or above(100m)

  Bandwidth

  22Gb Internal Bandwidth

  MAC Table

  64Kb

  Auto MDI-MDIX

  Yes All Port

  Console

  Yes – Web & RS232 Layer2 Managment (Telnet Support)

  Transfer Pattern

  Store & Forward

  Hardware

  Processore Type

  Realtek

  LED Panel

  Data Activity

  Main Board

  Double Layer

  Case

  Metal Case

  Mounting

  Rackmount

  PD`S

  IP Camera

  N/A

  IP Phone

  N/A

  (+)5/4,(-)8/7

  N/A

  (+)2/1,(-)6/3

  N/A

  General

  IP Rating

  IP51

  Web Language

  English

  Dimension

  275*181*54 mm

  Weight

  625 g

  Storage Temp

  -20°C ~ +60°C / 10% ~ 90% RH

  Operation Temp

  -15°C ~ +50°C / 10% ~ 90% RH

  Radiation Electromagnetic

  EN55016

  Status

  LED

  Ethernet Interfaces

  1000 LNK/ACT (Orange), 10/100 LNK/ACT (Green)

  Power Supply

  Power

  200~240V AC, 50~60Hz

  Redundant

  N/A

  LED Power

  Yes

  Power Cable

  Available

  Guarantee

  Product Guarantee

  3 Year Platinum Guarantee

  MTBF

  100K hrs min. MIL-HDBK-217F (25°)
