KI-B55ST60A-i70TSLM

70~80 m Smart IR SMD Technology

Smart White light Technology

PRODUCTS

Innovative Technology | Reliable Quality | End-to-End Service

KDT CCTV Camera Model KI-B55ST60A-i70TSL

Smart features:

> Crossing the line
> Virtual fence
> Entering the area
> Exiting the area
> Smart number traffic
> Heat map
> Facial recognition

> Intelligent Crowd Detection
> Rapid Movement Detection
> Camera Angle Change Detection
> People Pressing Detection
> Abnormal Sound Detection
> Lens Defocus Detection

KI-B55ST60F-i70TSLM

6MP Bullet Network Camera

> 6MP (Sony-Japan) Progressive scan Cmos Sensor (1/2.8”)
> 2.7~13.5 mm @F1.6, Motorized Fast Auto Focus Lens
> H.264+(Ultra H.264), H.265+ (Ultra H.265), MJPEG
> 30fps@ 6MP(3200*1800), 30fps@ 5MP, 30fps@ 4MP, 90fps@ 2MP
> Dual-Core ARM Cortex-A7@900 MHz
> Support PoE
> Triple Stream (Video Bit Rate:11 Kbps~16 Mbps)
> IP67, IK10, 6KV Surge Protection
> Internal Mic, Audio Out, Audio in
> Alarm In, Alarm Out

Other advantages:

> Supports Micro SD with a capacity of 256GB
> Waterproof and dustproof body with IP67, IK10
> Image transfer server in Iran
> Support for + H.264+ / H.265
> Support for ONVIF version 2.6
> Smart night vision ability
> WDR, BLC, HLC, Defog and ROI up to 8 areas
> Support for ANR emergency recording
> Support for EIS image stabilization technology
> Support for intelligent heat map technology

Warranty conditions:

> Five-year unconditional KDT gold warranty

> Six-year guarantee of image quality stability

> Including: water damage, breakage, impact, lightning damage, rust, power surges, other incidents and injuries

Camera
Image Sensor	6MP (Sony-Japan) Progressive scan CMOS Sensor (1/2.8″)
CPU	Dual-Core ARM Cortex-A7@900 MHz
Lens	2.7-13.5 mm @ F1.6, Motorized Fast Auto Focus Lens
Resolution	3200*1800 (6MP)
Available IR Range	70*80 m Smart IR SMD (Osram-Germany) Technology Smart White light Technology
D/N Filter	IR cut filter with auto switch
Min Illumination	Color: 0.001 Lux(AGC on) – B/W: 0 Lux(IR on)
Angle of View	H-FOV: 112°~36°, V-FOV: 58°~20°, D-FOV: 120°~39°
Night Vision	Color / IR
Picture Adjust
Picture Function	120dB WDR/DWDR, 2D/3D DNR, BLC, HLC, ROI, Defog
Image Stabilization	Yes (EIS)
Shutter Speed	Manual (1/3 ~ 1/100.000), Auto
Image Parameter Control	Off, On, Timing (Adjust 0 ~ 255)
D/N Control	Timing, Auto, Color on, Color off
S/N	> 56dB
Image Parameter	Saturation, Brightness, Contrast, Sharpness, Hue
Video / Audio
Video Compression	H.264+(Ultra H.264), H.265+ (Ultra H.265), MJPEG
Audio Compression	G.711A, G.711U
Frame Rate (60Hz)	30fps@ 6MP(3200*1800), 30fps@ 4MP, 90fps@ 2MP
Transmission Stream	Triple Stream (Video Bit Rate:11 Kbps~16 Mbps)
Network
Protocols	TCP/IP(V4, V6), ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, IGMP, UPnP, SMTP, UPnP-TM, P2P, SNMP (V1, V2, V3), UDP, NAT, Multicast, RTMP
Compatibility	Onvif Ver2.6, Profile S, G, T, CGI, SDK, API
Streaming Method	Unicast, Multicast
Web Viewer	IE, Edge, Firefox, Chrome
Function
Recording	FTP, NVR, CMS, VMS, NAS, SD Card, ANR
Record Type	Manual, Motion Detection, Smart Detection, Schedule
Alarm Triggers	All Intelligent Function
Event Action	Email, PTZ, Snapshot, Recording, Buzzer, Pop up, Show Message, Smart Light
Event	Smart Motion Detection, Video Shelter
Intelligent Function	13 Smart Functions, Line Crossing, Area Intrusion, Region Entrance, Region Exiting, Fast Moving, Loitering Detection, Blurred Detection, Scene Change Detection, Audio exception Detection, Smart People Counting, Face Detection, Smart People Counting, Crowd Density Monitoring, Heat Map
Interface
Network	1 RJ45 (10M / 100M) Ethernet Port
External Audio	Audio Out, Audio In
Internal Audio	Internal Mic
Alarm	Alarm In, Alarm Out
CVBS	N/A
Power	PoE LAN, DC In
Reset Button	Yes (Optional)
Memory Slot	Yes – Micro SD/SDHC/SDXC Slot (256 Gb Max) (ANR Support)
General
Protection Rating	IP67, IK10, 6KV Surge Protection
Power Supply	DC12V ± 10%
POE Supply	IEEE802.3af – Max 13 Watt
Web Language	English, Persian
Dimension	265*100 mm
Weight	1.4 kg
Operation Humidity	Humidity 95% or less (non-condensing)
Operation Temp	-30°C ~ +60°C
Guarantee
Product Guarantee	5 Years Gold Guarantee
MTBF	100K hrs min. MIL-HDBK-217F (25°)
Certificates	EN, CN, FCC, CFR
